Countersinks and drill bits

Q: How to distinguish a solid carbide cutter from an HSS cutter?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"Solid carbide is heavier, non-magnetic and has a fine grain visible under magnification. It sounds crystalline when tapped, unlike the dull sound of HSS. Carbide cutters are marked \"HM\" or \"Carbide\" with hardness 1500-2000 HV vs 800 HV for HSS. Carbide costs 3-5x more but lasts 10-20x longer at high speed, making the investment profitable in series production."}]}]}

Q: Can I use aluminum cutters on steel?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"Not recommended: aluminum cutters (2-3 flutes, 45° helix) evacuate steel's short chips poorly, causing jamming and breakage. Sharp edges optimized for aluminum dull quickly in steel. Use universal steel cutters (4 flutes, 30° helix) that work in both, or invest in specialized cutters if regular production: guaranteed long-term savings."}]}]}

Q: What rotation speed for Ø10mm carbide cutter in steel?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"Use the formula: RPM = (Cutting speed x 1000) / (3.14 x Diameter). "}]},{"type":"paragraph","children":[{"type":"text","value":"For mild steel typical carbide Vc=60-100m/min: (80 x 1000) / (3.14 x 10) = approximately 2550 RPM."}]},{"type":"paragraph","children":[{"type":"text","value":"Stainless steel Vc=40-60m/min = 1270-1910 RPM. "}]},{"type":"paragraph","children":[{"type":"text","value":"Aluminum Vc=150-300m/min = 4775-9550 RPM. "}]},{"type":"paragraph","children":[{"type":"text","value":"Adjust according to machine rigidity: reduce 20-30% if vibrations appear. Always consult manufacturer-specific data: "},{"url":"https://www.equipementpolar.com/en/collections/vendors?q=Eagle","title":"Eagle","type":"link","children":[{"type":"text","value":"Eagle"}]},{"type":"text","value":", "},{"url":"https://www.equipementpolar.com/en/collections/greenfield","title":"Greenfield","type":"link","children":[{"type":"text","value":"Greenfield "}]},{"type":"text","value":"and "},{"url":"https://www.equipementpolar.com/collections/vendors?q=Morse%20Cutting%20tool","title":"Morse Cutting Tools","type":"link","children":[{"type":"text","value":"Morse "}]},{"type":"text","value":"provide detailed tables by material, diameter and coating for maximum optimization."}]}]}

Q: How to avoid premature breakage of my cutters?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"Main causes: excessive speed (overheating), insufficient feed (friction), excessive depth (overload), lack of rigidity (vibrations), inadequate lubrication. Respect diameter/length ratio 1:3 maximum. Check spindle runout <0.005mm. Use clean ER collets without marks. Progressive load ramp eliminates initial shock. Monitor chip color: silver = optimal, blue = too hot, brown = critical wear."}]}]}

Q: Is resharpening worth the cost for carbide cutters?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"Yes if cutter >$75 and uniform wear without major chipping. Professional resharpening $25-40 restores significant performance. Cutter $150 resharpened 3x = total cost $240 vs $600 for 4 new ones. Savings $360 per tool. Not profitable for cutters <$40 or localized wear. Greenfield and Eagle accept resharpening with quality guarantee. Turnaround 5-10 days, plan buffer stock."}]}]}

Q: What warranty on your professional cutters?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"Manufacturer warranty against material/manufacturing defects: Eagle 90 days, Greenfield 6 months, Morse 1 year depending on range. Normal wear excluded. Breakage due to incorrect parameters not covered. Free technical service optimizes your settings preventing breakage. 30-day return if unused. Équipement Industriel Polar after-sales support in Quebec with permanent inventory of urgent replacement parts."}]}]}

(221 products)

When every micron carves perfection, your industrial milling cutters become the digital chisels of modern industry. And every tooth carves excellence into the toughest steel. That's why we have Eagle carbide cutters that gnaw flawlessly and Greenfield end mills that polish like glass. From high-performance Morse cutters to Fein cutting tools, our Canadian solutions transform your Canada CNC centers into workshops of absolute precision, cutting the impossible to a thousandth of a millimeter.

Milwaukee
CONCRETE DRILL BIT 1/4 X 2 X 4" MILWAUKEE

Regular price $4.35

Low stock (4 units)
Dewalt
SDS MAX CONCRETE DRILL BIT 1 1/8

Regular price $119.63

Very low stock (2 units)
Dewalt
SDS MAX CONCRETE DRILL BIT 1/2 X 8" DEWALT DW5803

Regular price $48.09

Very low stock (2 units)
Diablo
CONCRETE DRILL DB SDS-PLUS FCH 4C 9/16X6X18

Regular price $29.31

Very low stock (2 units)
Greenfield
DRILL #13 HSS REG. KEY-LINE C22700

Regular price $2.45

Low stock (8 units)
Sold out

Greenfield
DRILL BIT 1 1/16 BLACK KEY-LINE C20758

Regular price $69.93
Dewalt
DEWALT 8-1/4" 24-TOOTH STRUCTURAL LUMBER BLADE DEWALT DWA281424

Regular price $18.99

Low stock (5 units)
Diablo
6'' 10 TEETH DIABLO CARBIDE BLADE

Regular price $16.63

Low stock (5 units)
Dewalt
BLADE 7-1/4 FIBER CEMENT DEWALT DWA3193PCD

Regular price $90.55

Low stock (5 units)
Procut
ADJUSTABLE REAMER

Regular price From $35.71

Low stock (10 units)
Procut
STRAIGHT CLAMPING REAM

Regular price From $15.57

In stock (20 units)

Complete guide to choosing your professional industrial cutters

How to choose the right milling cutter for your material to be machined?

The choice depends mainly on the material: aluminum requires 2-3 flutes with a high helix angle (38-45°) for fast evacuation of long and sticky chips. Steel requires 4 flutes with a moderate helix angle (30-35°) and a TiAlN coating resistant up to 800°C. Carbide end mills offer superior durability for hard steels and prolonged machining without frequent sharpening.

Titanium requires sharp-edged end mills with ample lubrication to prevent sticking and welding on the tool. Plastics require polished flutes and moderate to high speed to prevent melting of the material. Depth of cut varies: 0.3-0.5x diameter for finishing, 1-1.5x for roughing depending on machine rigidity. Eagle and Greenfield offer specialized ranges by material with detailed selection guides.

What cutter geometry to optimize your machining speeds?

Geometry directly influences performance: 2-flute cutters efficiently remove chips at 8000-15000 RPM in aluminum, ideal for deep grooves. 4-flute cutters offer superior finishing at 6000-10000 RPM in steel with improved cutting stability. The helix angle determines the cutting force: 30° = general purpose steel, 38-45° = aluminum fast removal, 10-15° = hard materials.

The tip radius significantly influences tool life. Interchangeable carbide-tipped cutters significantly reduce operating costs. The optimal cutting length respects the diameter-to-length ratio for maximum rigidity. Eagle and Greenfield specify parameters according to material: mild steel 60-100m/min, aluminum 150-300m/min with carbide.

Coating technologies: TiN, TiAlN or diamond for your cutters?

The gold-colored TiN (titanium nitride) coating increases hardness to 2000-2400 HV and withstands up to 600°C, significantly extending service life in standard steel. The purple-gray TiAlN (titanium-aluminum) withstands 800-900°C, essential for stainless steels and heat-resistant alloys with hardness 2000-3500 HV. The AlTiN coating achieves superior performance in high-speed machining.

Morse Cutting Tools and Fein develop multi-layer coatings with alternating compositions for optimal heat resistance. Uncoated K40 carbide cutters remain efficient for general applications. Polished flutes significantly reduce friction, improving chip evacuation. Eagle offers ranges with specific coatings for industrial applications.

CNC applications: which cutter for lathe, milling machine and machining center?

3-axis CNC centers use ball-end milling cutters for complex surfaces: small radii for fine details, large radii for rapid roughing. Conventional milling machines favor straight 2-sided cutters for grooving depending on the available power. CNC lathes equipped with integrated milling require short, rigid cutters to minimize vibration.

5-axis machining requires long end mills with reduced necks that can access deep cavities without collision. Eagle catalogs various references covering multiple diameters and lengths. Small diameter micro end mills are used in the medical and electronics sectors with tight tolerances. Greenfield and Morse offer complete ranges according to applications: roughing, semi-finishing, finishing with optimized geometries.

Maintenance and optimization: extend the life of your carbide cutters

Post-use cleaning with a degreasing solvent removes residue that reduces future performance. Visual inspection detects microscopic chips, warranting early replacement before breakage. Professional regrinding restores significant performance at a fraction of the original price, cost-effective for premium cutters. Micro-spray lubrication (MQL) uses minimal amounts of coolant compared to conventional coolant, reducing costs and environmental impact.

Optimal settings vary depending on the application: low feed for finishing, high feed for productive roughing. Vibration monitoring detects progressive wear before catastrophic failure. Eagle, Greenfield, and Morse offer technical support to optimize settings for customer-specific machines and materials.

Cutting Drills Measuring tools Mandrels and Drill Bit Cutting tools Taps and dies Workshop Storages

We answer your questions about industrial strawberries

How to distinguish a solid carbide cutter from an HSS cutter?

Solid carbide is heavier, non-magnetic and has a fine grain visible under magnification. It sounds crystalline when tapped, unlike the dull sound of HSS. Carbide cutters are marked "HM" or "Carbide" with hardness 1500-2000 HV vs 800 HV for HSS. Carbide costs 3-5x more but lasts 10-20x longer at high speed, making the investment profitable in series production.

Can I use aluminum cutters on steel?

Not recommended: aluminum cutters (2-3 flutes, 45° helix) evacuate steel's short chips poorly, causing jamming and breakage. Sharp edges optimized for aluminum dull quickly in steel. Use universal steel cutters (4 flutes, 30° helix) that work in both, or invest in specialized cutters if regular production: guaranteed long-term savings.

What rotation speed for Ø10mm carbide cutter in steel?

Use the formula: RPM = (Cutting speed x 1000) / (3.14 x Diameter).

For mild steel typical carbide Vc=60-100m/min: (80 x 1000) / (3.14 x 10) = approximately 2550 RPM.

Stainless steel Vc=40-60m/min = 1270-1910 RPM.

Aluminum Vc=150-300m/min = 4775-9550 RPM.

Adjust according to machine rigidity: reduce 20-30% if vibrations appear. Always consult manufacturer-specific data: Eagle, Greenfield and Morse provide detailed tables by material, diameter and coating for maximum optimization.

How to avoid premature breakage of my cutters?

Main causes: excessive speed (overheating), insufficient feed (friction), excessive depth (overload), lack of rigidity (vibrations), inadequate lubrication. Respect diameter/length ratio 1:3 maximum. Check spindle runout <0.005mm. Use clean ER collets without marks. Progressive load ramp eliminates initial shock. Monitor chip color: silver = optimal, blue = too hot, brown = critical wear.

Is resharpening worth the cost for carbide cutters?

Yes if cutter >$75 and uniform wear without major chipping. Professional resharpening $25-40 restores significant performance. Cutter $150 resharpened 3x = total cost $240 vs $600 for 4 new ones. Savings $360 per tool. Not profitable for cutters <$40 or localized wear. Greenfield and Eagle accept resharpening with quality guarantee. Turnaround 5-10 days, plan buffer stock.

What warranty on your professional cutters?

Manufacturer warranty against material/manufacturing defects: Eagle 90 days, Greenfield 6 months, Morse 1 year depending on range. Normal wear excluded. Breakage due to incorrect parameters not covered. Free technical service optimizes your settings preventing breakage. 30-day return if unused. Équipement Industriel Polar after-sales support in Quebec with permanent inventory of urgent replacement parts.
