Dies and punches

Q: Are Metabo HPT dies compatible with other brands?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"Metabo HPT dies are primarily designed for their proprietary "},{"type":"text","value":"CN16 nibblers","bold":true},{"type":"text","value":". For universal compatibility, consider "},{"type":"text","value":"Cleveland Punch & Die","bold":true},{"type":"text","value":" or "},{"type":"text","value":"Ajax","bold":true},{"type":"text","value":", which fit about "},{"type":"text","value":"90% of standard presses","bold":true},{"type":"text","value":". Mounting dimensions vary — always check shank diameter, total height, and locking system. Équipement Industriel Polar offers a free compatibility verification service before purchase."}]}]}

Q: How can I extend the lifespan of my punches?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"Sharpen punches every "},{"type":"text","value":"5,000 strokes","bold":true},{"type":"text","value":" using a fine-grit stone, maintaining the original angle. Always lubricate with proper cutting oil for the material used. Avoid “dry hits” that can chip the edges. Replace both die and punch together to maintain the correct clearance. Store in a dry, corrosion-protected environment. With proper maintenance, lifespan can reach "},{"type":"text","value":"150,000 cycles","bold":true},{"type":"text","value":" versus only "},{"type":"text","value":"50,000 without upkeep","bold":true},{"type":"text","value":"."}]}]}

Q: Which press should I use with Cleveland Punch & Die sets?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"\nCleveland designs its dies for standard 10–150 ton presses. Required force can be estimated as:\n\n"},{"type":"text","value":"Force (tons) ","bold":true},{"type":"text","value":"= hole perimeter (in) × material thickness (in) × shear strength (PSI) ÷ 2000.\n\nExample: a 1\" hole in 1/4\" steel requires about 20 tons. F-series dies suit light presses (10–30T), while C-770 dies fit heavy-duty presses (30–100T+). Always verify your press capacity before purchasing.\n\n"}]}]}

Q: How do I choose the right die size for my project?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"Die size = desired hole diameter plus clearance."}]},{"type":"list","listType":"unordered","children":[{"type":"list-item","children":[{"type":"text","value":"For "},{"type":"text","value":"steel","bold":true},{"type":"text","value":", add "},{"type":"text","value":"10%","bold":true},{"type":"text","value":" of material thickness."}]},{"type":"list-item","children":[{"type":"text","value":"For "},{"type":"text","value":"aluminum","bold":true},{"type":"text","value":", add "},{"type":"text","value":"15%","bold":true},{"type":"text","value":"."}]},{"type":"list-item","children":[{"type":"text","value":"For "},{"type":"text","value":"stainless steel","bold":true},{"type":"text","value":", add "},{"type":"text","value":"20%","bold":true},{"type":"text","value":"."}]}]},{"type":"paragraph","children":[{"type":"text","value":"Example: a 1\" hole in 1/4\" steel → 1.025\" die. Use a punch 0.002–0.005\" smaller than the die for optimal slug clearance. Cleveland includes detailed size selection charts with every product."}]}]}

Q: What’s the difference between a round and an oblong die?

{"type":"root","children":[{"type":"paragraph","children":[{"type":"text","value":"Round dies create perfectly circular holes from 1/8\" to 4\", ideal for bolts, fasteners, and piping. Oblong dies produce rectangular or oval openings up to 2\" × 4\", perfect for cable pass-throughs, ventilation, or access slots."}]},{"type":"list","listType":"unordered","children":[{"type":"list-item","children":[{"type":"text","value":"Use "},{"type":"text","value":"round","bold":true},{"type":"text","value":" for mechanical assembly."}]},{"type":"list-item","children":[{"type":"text","value":"Use "},{"type":"text","value":"oblong","bold":true},{"type":"text","value":" for wiring or clearance needs."}]}]},{"type":"paragraph","children":[{"type":"text","value":"Oblong dies cost "},{"type":"text","value":"20–30% more","bold":true},{"type":"text","value":", but save significant time by eliminating multiple drilling steps."}]}]}

(283 products)

Dies and punches transform raw metal into millimeter-precise tools. Our punch and die collection includes high-strength steel punches and aluminum punches for light-duty applications, all engineered to drill, cut, and stamp with surgical accuracy. From Cleveland Punch & Die dies that cut through steel like butter to oblong punches that sculpt the impossible, our arsenal of 250+ stamping tools from Québec redefines industrial metallurgy. Ruthless round dies up to 4", surgical Mayhew pin punches, tolerances ±0.0005": equip your presses with the precision that has shaped Canadian industry since 1982.

ATD
110PCS HYDRAULIC ADJUSTMENT ASSORTMENT ATD-357

Regular price $21.45

Very low stock (2 units)
Lincoln Lubrification
MULTIPURPOSE HYDRAULIC COUPLER FOR GREASE GUN

Regular price $7.15

In stock (15 units)
Lincoln Lubrification
HEAVY DUTY HYDRAULIC COUPLER 7,500 PSI MAX.

Regular price $24.25

In stock (16 units)
Lincoln Lubrification
FITTING FOR GREASE GUN (5)

Regular price $43.15

Low stock (9 units)
Wakefield
HYDRAULIC OIL AW32 19L.

Regular price $117.00

Low stock (4 units)
Wakefield
HYDRAULIC OIL AW68 19L.

Regular price $82.99

Low stock (5 units)
Uview
8OZ A/C OIL UVIEW

Regular price $14.40

Very low stock (1 unit)
LPS
ANTI SEIZE LPS 1LB LPS

Regular price $76.42

Very low stock (2 units)
Sold out

Orapi
ANTI-SIZE ALUMINUM SPRAY ORAPI

Regular price $38.18
Tap Magic
CUTTING FLUID TAP MAGIC AQUEOUS 16OZ

Regular price $20.59

In stock (17 units)
Champion
DRILL TAP 1/4-20 HSS CHAMPION DT22HEX-1/4-20

Regular price $23.09

Very low stock (1 unit)
Sold out
Dewalt
60V MAX FLEXVOLT PIPE THREADER KIT W/HEADS

Regular price $3,479.00

Complete guide to choosing your professional dies and punches

Why are industrial-grade steel punches and dies essential?

Professional steel punches and precision dies guarantee an accuracy of ±0.001" on each perforation, critical for the Quebec aerospace and manufacturing industries. Cleveland Punch & Die, our flagship brand with over 228 models, uses D2 steel hardened to 60-62 HRC for its punch dies, which can withstand over 100,000 cycles without deformation.

Our specialized aluminum punches excel in light-duty applications requiring less punching force. Modern stamping dies enable speeds of up to 60 strokes per minute on steel up to 6 mm thick. Investing in quality tooling reduces rejects by 95% and increases productivity by 40%, making the purchase profitable in less than 6 months with daily use.

What are the technical specifications for your Canada punch die?

The specifications of Canada die punches determine their performance on steel and aluminum. Round dies range from 1/8" to 4" in diameter, ideal for standard holes, while our high-hardness steel punches (60-62 HRC) excel on ferrous metals. Oblong dies allow for openings up to 2" x 4" for cable passages.

Critical hardness: 58-62 HRC for mild steel, 62-65 HRC for stainless steel. The optimal die-punch clearance is 10% of the material thickness for steel, 15% for aluminum, as our specialized aluminum punches require less penetration force. Cleveland models offer tolerances of ±0.0005", while Ajax models are suitable for less critical work with ±0.002".

Advanced technologies in modern Quebec stamping tools

Steel punches and punch-die assemblies are suitable for every manufacturing sector in Quebec. In metal fabrication, our high-strength steel punches and F-62 dies pierce structural steel for construction with surgical precision. The electrical industry uses oblong punches for control panels.

The aerospace industry favors our specialized aluminum punches and Starrett dies for aircraft-grade aluminum, offering clean, burr-free cuts. Repair shops prefer Mayhew 19-piece kits for maximum versatility. Each application requires precise selection: hole shape, material thickness, production rate, and required finish determine the optimal choice between steel and aluminum punches.

Aluminum and steel punches: How to excel in every application?

Industrial punches adapt to every manufacturing sector in Quebec. In metal fabrication, F-62 dies pierce structural steel for construction. The electrical industry uses oblong punches for control panels. Aerospace favors Starrett dies for aircraft aluminum. Repair shops prefer Mayhew 19-piece kits for maximum versatility. Each application requires precise selection: hole shape, material thickness, production rate, and required finish determine the optimal choice.

Maintenance and compatibility of professional industrial punches

Maintaining industrial punches maximizes their longevity and accuracy. Regular sharpening every 5,000 strokes maintains sharp edges, reducing stress by 30%. Constant lubrication with EP oil prevents overheating and seizure. Cleveland dies are compatible with 90% of standard presses on the market. Storage in a controlled environment (humidity <50%) prevents corrosion. Synchronized die-punch replacement prevents premature wear. A preventative maintenance program can triple the service life, from 50,000 to 150,000 cycles.

Punches and scissors Pliers and cutters Manual tools Air Hammers Indicators Oscillating tools Boring Tools Makita Bits

We answer your questions about dies and punches and professional tools

Are Metabo HPT dies compatible with other brands?

Metabo HPT dies are primarily designed for their proprietary CN16 nibblers. For universal compatibility, consider Cleveland Punch & Die or Ajax, which fit about 90% of standard presses. Mounting dimensions vary — always check shank diameter, total height, and locking system. Équipement Industriel Polar offers a free compatibility verification service before purchase.

How can I extend the lifespan of my punches?

Sharpen punches every 5,000 strokes using a fine-grit stone, maintaining the original angle. Always lubricate with proper cutting oil for the material used. Avoid “dry hits” that can chip the edges. Replace both die and punch together to maintain the correct clearance. Store in a dry, corrosion-protected environment. With proper maintenance, lifespan can reach 150,000 cycles versus only 50,000 without upkeep.

Which press should I use with Cleveland Punch & Die sets?

Cleveland designs its dies for standard 10–150 ton presses. Required force can be estimated as:

Force (tons) = hole perimeter (in) × material thickness (in) × shear strength (PSI) ÷ 2000.

Example: a 1" hole in 1/4" steel requires about 20 tons. F-series dies suit light presses (10–30T), while C-770 dies fit heavy-duty presses (30–100T+). Always verify your press capacity before purchasing.

How do I choose the right die size for my project?

Die size = desired hole diameter plus clearance.

For steel, add 10% of material thickness.
For aluminum, add 15%.
For stainless steel, add 20%.

Example: a 1" hole in 1/4" steel → 1.025" die. Use a punch 0.002–0.005" smaller than the die for optimal slug clearance. Cleveland includes detailed size selection charts with every product.

What’s the difference between a round and an oblong die?

Round dies create perfectly circular holes from 1/8" to 4", ideal for bolts, fasteners, and piping. Oblong dies produce rectangular or oval openings up to 2" × 4", perfect for cable pass-throughs, ventilation, or access slots.

Use round for mechanical assembly.
Use oblong for wiring or clearance needs.

Oblong dies cost 20–30% more, but save significant time by eliminating multiple drilling steps.
