- Oil lubricated for cooler operation and reduced noise
- High-efficiency cast iron pump provides maximum performance and lifespan
- Big BoreTM cylinder and piston deliver high efficiency at lower RPM with reduced heat build-up, less noise and longer life
- Low amperage reduces incidents of tripped circuit breakers and voltage drops that cause premature motor failure
- Easy-to-view oil gauge and large pressure gauges for quick identification
- Air pressure regulator allows easy adjustment of line pressure
- Includes 2 quick connect air hose fittings
- Finned discharge tube promotes safe and efficient cooling
- Safety cage construction protects components from damage
INCLUDES: 1/4" quick connect, (10TT-8), Compressor oil (0.25 L) (181122-A)
|
Engine
|
2.5 hp
|
|
Pump
|
Oil lubricated |
|
Reservoir
|
2 x 2.1 gallons
|
|
Performance (90 psi)
|
4.2 PCM
|
|
Noise level
|
79dB(A)
|
|
AMP (120V)
|
12.3A |
|
Dimensions (L x W x H)
|
20-1/2" x 19-5/8" x 20-7/8" (520 mm x 497 mm x 530 mm)
|
|
Maximum pressure
|
130 pounds per square inch |
|
Net weight
|
77.0 lbs (34.9 kg) |
|
|
